An end shield looks like a simple disc. It is not. It carries the bearing or bush seat, and if that seat is off by a fraction the rotor sits crooked, the motor draws more current, runs hot and comes back to you as a complaint.
We machine the seat square and hold the bore to tolerance, and we gauge across the lot rather than checking a sample. That is the whole reason assemblers buy end shields from a motor manufacturer instead of a trader.
Rings drawn to relative scale. Pick the one that matches the shield you are replacing, and the WhatsApp message opens filled in.
Not sure which one you have? Photograph the old shield next to a measuring tape — that is enough for us to identify it.
Send a photo insteadFour frame sizes, two materials. Tell us the frame and the material and we quote the same day.
H-Frame
The size the repair market runs out of every April. Fits H-Frame cooler motor bodies from 32mm through 51mm shaft. Front and rear shields supplied as a matched pair or loose. Bearing housing machined square so the rotor centres without shimming.
Get rate
E-Frame
Built around the 120.4 ring for E-Frame cooler motor bodies, the standard fitment on branded cooler assemblies. Bore held to tolerance so the shaft aligns straight off the rack. Available with bush or bearing seat.
Get rate
Dia Series
Fits our 110 Dia bush and cuppa mount range and the standard 110 bodies used across the market. Seats machined for both bush and bearing versions, so the same shield covers most 110 assemblies on a line. Stocked through the season.
Get rate
Type 200
For exhaust and cooler bodies built to the Type 200 standard, including our EX32BE and EX38BE exhaust range. Bearing seat machined square for continuous-duty running, where a loose seat shows up as noise within weeks. Matched to your sample.
Get rate
Material
Our standard on H-Frame and E-Frame. Lighter than shell, and it sheds heat through the ribbing instead of trapping it against the winding. Available across 139 dia, 120.4 dia, 110 dia and Type 200. Also asked for as aluminium motor cover.
Get rate
Material
Mild steel shell for rental, tent-house and rough-handling duty, where a cooler gets thrown on a truck twice a week. Takes a knock without cracking, and prices below aluminium for volume buyers. Same four sizes.
Get rateEvery one of these names refers to the same part. Whichever you use, we know what you mean.
Material and seat type confirmed against your sample before we quote.
| Frame | Diameter | Fits | Seat | Material |
|---|---|---|---|---|
| H-Frame | 139 mm | H32BE · H38BE · H44BE · H51BE | Bearing | Aluminium / MS shell |
| E-Frame | 120.4 mm | EF28BU · EF32BU | Bush | Aluminium / MS shell |
| 110 Dia | 110 mm | 11028BU · 11032BU · 11038BU · 11028CU · 11032CU | Bush / Cuppa | Aluminium / MS shell |
| Type 200 | Frame standard | EX32BE · EX38BE exhaust range | Bearing | Aluminium / MS shell |
Rates are market-linked and shared on enquiry with current stock position. All prices ex-GST; 18% GST extra.
Tell us the frame, the diameter and the material — or send a photo of the shield you are replacing with a tape next to it. We identify it against our tooling and come back with a rate and a delivery date.
Minimum order quantity applies per size and material. GST invoice with every dispatch, 18% GST extra on ex-GST rates. Transport to your address at buyer's cost.
Start an orderH-Frame 139 dia, E-Frame 120.4 dia, 110 dia and Type 200. Each is available in die-cast aluminium and mild steel shell.
Yes. The same part is called an end shield, end cover, shell cover, end cap, aluminium cover or MS end cover depending on the buyer and the region. All of them refer to the machined disc that closes the motor body and carries the bearing or bush seat.
Die-cast aluminium is lighter and sheds heat better, which is why it is our standard on H-Frame and E-Frame motors. Mild steel shell is tougher for rental and rough-handling duty and prices below aluminium for volume buyers. If the cooler is transported often, take MS.
Send a photo of the end shield you are replacing on WhatsApp, with a measuring tape next to it if you can. Give us the outer diameter and the bore if you are able to measure them. We match it against our tooling and confirm the same day.
Yes. Rewinders and assemblers who wind in-house are a large part of this business. Dimensions are held consistent lot to lot, so fitment does not change between batches and your line does not have to shim.
A minimum order quantity applies per size and material. Share the size and quantity you need on WhatsApp and we will confirm the current MOQ along with the rate.
Yes. If you buy our H-Frame, E-Frame, 110 Dia or Type 200 motors, the shields come off the same tooling, so the fit is exact. Mention your motor SKU in the enquiry.
Yes, pan-India. Transport is arranged to your address at buyer's cost and tracking is shared on WhatsApp after dispatch.
139 dia, 120.4 dia, 110 dia and Type 200 — aluminium or MS shell, machined and gauged in Faridabad.
